Intel FALCON 8+ Flight Manual

MAINTENANCE MANUAL
INTEL
®
FALCON™ 8+ UAS
LIMITATIONS
20 © 2017 Intel Corporation. All rights reserved.
REV 00
APR 2017
ENERGY LIMITATIONS
2.8.1 Maximum Mission Endurance
MAXIMUM MISSION ENDURANCE
26 minutes
1
OTHER LIMITATIONS
Do not make any unapproved modifications to the Intel
®
Falcon™ 8+ UAS.
Do not transport the system in containers not approved by Intel Corporation.
Do not disassemble the aircraft.
2.9.1 GPS Mode
In this mode the inputs via the Intel
®
Cockpit Ground Control Station (GCS) directly control the
speed of the UAS. For example moving the right control stick completely to the left (which
controls pitch and roll) means the system will fly at 10 mph (4.5 m/s) to the left, independent of
the wind strength and direction.
For safety reasons and to make operation as easy as possible, there are some limitations:
 Roll and pitch angles are limited to 45°.
 Speed in horizontal plane is limited to 10 mph (4.5 m/s).
 Ascend rate is limited to 6 mph (3 m/s).
 Descend rate is limited to 6 mph (3 m/s).
GPS Accuracy
The GPS module of the Intel
®
Falcon™ 8+ UAS supports GPS and GLONASS. Under ideal
conditions, the horizontal accuracy can reach around +/- 6.5 ft. (2 m).
1
Varies based on payload weight, battery conditions, and environmental conditions.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
