Intel FALCON 8+ Flight Manual

MAINTENANCE MANUAL
INTEL
®
FALCON™ 8+ UAS
NORMAL PROCEDURES
36 © 2017 Intel Corporation. All rights reserved.
REV 00
APR 2017
o Other Pilots and Remote Pilots in the area
o Situation coordinator
o On site emergency personnel
If traffic exists, coordinate flight plan with Pilots and Remote Pilots.
Weather Station Set up
Communications Establish
Ensure appropriate communications equipment is available when the Pilot and Visual
Observer are positioned beyond vocal range. If operating in an area where other operators,
aircraft, or emergency personnel are present, ensure proper notification has been made of
intended flight area and duration of operation.
ASSEMBLING THE UAS
4.3.1 Installing the Camera Mount
1. Feed the Camera Mount’s carbon rod, without thumbscrew, into the hole on the front
side of the Central Unit.
2. Adjust the Payload Adapter into place.
Note: During the assessment of field conditions if a determination is made that hazards
are present, perform a risk assessment and implement mitigating procedures.
Note: Make sure the Camera Mount comes out straight and not at an angle.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
