Intel FALCON 8+ Flight Manual

DESCRIPTION
© 2017 Intel Corporation. All rights reserved. 101
REV 00
APR 2017
7.4.3 Sony Alpha 7R Full Frame Camera
The Sony Alpha 7R is the payload recommended for survey, inspection and aerial photography.
Specifications:
 Sensor size: 35.90 mm x 24.00 mm
 Resolution: 36.4 Mpx (7360 x 4912
pixels)
 Lens: Sonnar® T* FE 35 mm F2.8 ZA
(SEL35F28Z)
 Weight incl. lens and gimbal: ~ 790 g.
 Approx. max. flight time: 12 min
 Approved lenses:
o Sonnar® T* FE 35 mm F2.8 ZA
(SEL35F28Z)
o All other available full frame lenses are too heavy and are not approved.
Images are stored on an SD card, which is inserted underneath a lid on the right back side of the
camera.
To transfer images to the computer, use an SD card reader which is connected to the computer.
Camera Settings
The most important functions can be quickly accessed via the buttons:
1) Fn: see below
2) MENU: see below
3) C2: provides quick access to the Focus
Mode
4) WB: provides quick access to White
Balance.
ISO can be quickly accessed by turning the
control wheel in the back of the camera.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
