Intel FALCON 8+ Flight Manual

MAINTENANCE MANUAL
INTEL
®
FALCON™ 8+ UAS
EMERGENCY PROCEDURES
26 © 2017 Intel Corporation. All rights reserved.
REV 00
APR 2017
SECTION 3 EMERGENCY PROCEDURES
INTRODUCTION
This Section describes the recommended procedures for coping with various types of
emergencies or critical situations that may occur whilst in flight. These emergencies may be
caused by aircraft or engine malfunctions, weather emergencies, malfunctions or other
abnormalities that are not of emergency nature. Should an emergency arise, the basic
guidelines described in this section should be considered and applied as necessary to correct
the issue.
EMERGENCY PROCEDURES CHECKLIST
Procedures in the Emergency Procedures Checklist portion of this section shown in boldfaced
type are immediate action items which should be committed to memory.
PROPULSION FAILURES
3.3.1 Propulsion Failure on Takeoff
1. Land immediately
2. Visual Contact with Aircraft Maintain Through Landing
3. Flight Path Monitor
4. Shutdown Checklists Complete
3.3.2 Propulsion Failure during Flight
1. Land immediately
2. Visual Contact with Aircraft Maintain Through Landing
3. Flight Path Monitor
4. Shutdown Checklists Complete
FIRES
3.6.1 During Start on Ground
1. Left Control Down
2. START/STOP Switch 1 second
3. Shutdown Checklists Complete

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
