Intel FALCON 8+ Flight Manual

MAINTENANCE MANUAL
INTEL
®
FALCON™ 8+ UAS
SERVICE / MAINTENANCE
118 © 2017 Intel Corporation. All rights reserved.
REV 00
APR 2017
Motor Rail Installation
 Plug the Motor Rail to the Center Cross, ensuring both pins of the Center Cross are
correctly inserted to the jacks of the Motor Rail.
 Apply a thread locking agent to the screws.
 Using a T6 Torx screwdriver, screw in to two Motor Rail screws.
 Ensure the Propellers rotate in the correct direction.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
