Intel FALCON 8+ Flight Manual

MAINTENANCE MANUAL
INTEL
®
FALCON™ 8+ UAS
DESCRIPTION
82 © 2017 Intel Corporation. All rights reserved.
REV 00
APR 2017
GPS-Mode
When there is no input from the Remote Pilot, the system will:
 Keep its orientation in the air;
 Maintain its position within the limits of the GPS accuracy (approx. 2-5 m);
 Keep its height within the limits of the height controller (approx. 1-3m);
 Compensate for wind speed up to 27 mph (12 m/s).
The inputs via the Intel
®
Cockpit GCS control the speed of the Intel
®
Falcon™ 8+ UAS directly.
 Roll and pitch angles are limited to 45°.
 Speed in horizontal plane is limited to 10 mph (4.5 m/s).
 Ascend rate is limited to 7 mph (3 m/s).
 Descend rate is limited to 7 mph (3 m/s).
Height-Mode
When there is no input from the remote Pilot, the system will only:
 Keep its orientation in the air;
 Keep its height within the limits of the height controller (approx. 1-3m).
The system will neither keep its position nor compensate for wind.
The position must be held manually by the Remote Pilot.
The inputs via the Intel
®
Cockpit GCS control the roll and pitch angles of the Intel
®
Falcon™ 8+
UAS.
 Roll and pitch angles are limited to 50°.
 The direction and the speed of the Intel
®
Falcon™ 8+ UAS are influenced by the wind
direction and speed.
 Ascend rate is limited to 7 mph (3 m/s).
 Descend rate is limited to 7 mph (3 m/s).
CAUTION: AVOID FULL THROTTLE INPUTS IN HEIGHT-MODE AS THE INTEL® FALCON™ 8+ UAS
CAN BE OVERSTRESSED IN CERTAIN SITUATIONS, E.G. FLYING ABRUPT MANEUVERS
WITH A LOW BATTERY.
CAUTION: WHEN THE GPS QUALITY IS INSUFFICIENT, HEIGHT-MODE WILL AUTOMATICALLY
BE ACTIVATED. AT THIS POINT, POSITIONAL ACCURACY MIGHT ALREADY BE TOO
LOW AND IT IS STRONGLY RECOMMENDED TO ACTIVELY SWITCH TO HEIGHT-MODE
IN SITUATIONS WITH INSUFFICIENT GPS QUALITY.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
