USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 142
4. Use the right control stick to maintain the current position as precisely as possible,
while carefully moving down the left control stick to descend slowly.
5. Right before touch-down – at a height of 0.2 - 0.3 m – move the left control stick
down gradually until the UAV lands on the ground. While the Intel® Falcon™ 8+ UAV
is on the ground with running motors, always keep the left control stick in the fully
downward position to avoid any unintentional take-off.
6. Keep the left control stick in the fully downwards position, and use the right hand to
simultaneously press the START/STOP button on the CTR for at least one second to
stop the motors.
7. Follow the post-flight check (“POST-FLIGHT CHECK” on page 16) to safely switch
off and store away the complete system.
3.11.3. Landing in Manual-Mode
In Manual-Mode the pilot must control all axes directly as there is no automation
assisting control, nor preventing pilot errors.
1. Activate the Manual-Mode.
2. Fly the UAV to a position above the desired landing area at a safe height of at least 3
meters.
3. Descend slowly to a height of 1.5 meters and wait until the UAV is stabilized.
4. Use the right control stick to maintain the current position as precisely as possible,
while carefully moving down the left control stick to descend slowly.
5. Right before touch-down – at a height of 0.2 - 0.3 m – move the left control stick
down gradually until the UAV lands on the ground. While the Intel® Falcon™ 8+ UAV
is on the ground with running motors, always keep the left control stick in the fully
downward position to avoid any unintentional take-off.
6. Keep the left control stick in the fully downwards position, and use the right hand to
simultaneously press the START/STOP button on the CTR for at least one second to
stop the motors.
7. Follow the post-flight check (“POST-FLIGHT CHECK” on page 16) to safely switch
off and store away the complete system.
CAUTION: LANDING IN MANUAL-MODE IS FOR EXPERTS ONLY.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
