USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 82
2.7.1. Packing Instructions
To ensure a safe and optimal transport of your flight system, please see the images
below for the right boxing.
CAUTION: WHEN SHIPPING THE INTEL® FALCON™ 8+ UAV IN THE
TRANSPORT CASE WITH A MOUNTED PAYLOAD, YOU MUST USE
THE FOAM INLET OF THE PAYLOAD CASE TO AVOID DAMAGES
DURING TRANSPORT OR YOU MUST TRANSPORT IT IN THE SPECIAL
PAYLOAD CASE (SEE FOLLOWING).
Figure 2.37: Packing Instructions for the Intel® Falcon™ 8+ UAS Cases
Intel® Falcon™ 8+ System Case
This case is used for all necessary parts of
your Intel® Falcon™ 8+ UAV.
Following the numbers, the slots contains:
(1) Intel® Falcon™ 8+ UAV without payload
(2) Power supply units for charging the
Intel® Powerpack batteries (6)
(3) Space for accessories, e.g. sunglasses
(4) Toolkit with spare propellers (see
below)
(5) Space for the payload when mounted
directly on the UAV.
For load security, you must take the
foam bolster inlet supplied with the
payload case.
(6) Space for the Intel® Powerpack
batteries (optional, shipped separately)
(7) ICC gamepad (optional)
(8) Space for extra equipment, if any, that
is not part of the System, e.g. reflective
safety vest or video goggles
Toolkit and spare parts
1
2
2
3
4
5
6
7
8

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
