USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 212
6.2. TROUBLESHOOTING
This chapter describes solutions for special problems.
6.2.1. Establishing a connection between the CTR and the
UAV
The UAV and the CTR are pre-configured ex works.
Nevertheless, when the Intel® Falcon™ 8+ UAV and the CTR are powered up for the first
time, the Status Display will show the Start Screen and it is necessary to set up the
connection between UAV and CTR.
If the UAV and the respective CTR have been linked before, the UAV will automatically
connect to the CTR as soon as both are turned on.
In some cases, it may be necessary to establish the connection manually again.
Note
It saves some time to switch on the UAV first, so that the system check is being
carried out. Then switch on the touchscreen tablet followed by the CTR.
Figure 6.9: Connecting the CTR to the UAV
If the UAV and the CTR do not automatically connect, the
Status Display will note it in the Start Screen. If this is the
case, you must establish the connection manually.
1. Push the ENT button of the Status Display (see
“STATUS DISPLAY” on page 166). You will see the
screen to enter the Falcon Serial number (5-digit serial
number of the Intel® Falcon™ 8+ UAV, printed on the
top of the UAV, above the battery compartment, for
example 31123). The first digit is highlighted (see
figure below).

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
