Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 167
4.1.1. Status Display Menu Structure
For further information in terms of the Status Display see “The Status Display” on
page 27.
Table 4.1: Status Display Menu Structure
After switch-
ing on the CTR
the first screen
you see on the
Status Display
is the
Welcome
Screen.
After some
seconds, the
screen
changes to the
Start Screen.
If the UAV is
switched on
and there is no
connection
established to
the CTR, you
should push
ENT. The fol-
lowing screen
appears:
For entering
the serial num-
ber see “Estab-
lishing a
connection
between the
CTR and the
UAV” on
page 212.
By pushing the
RIGHT arrow
button the lati-
tude and lon-
gitude of the
last known
position of the
UAV are
shown:
Pushing ESC
on the screen,
with last
known posi-
tion, brings
you back to
the Main
Screen.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
