USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 31
2.5. PAYLOADS - CAMERA OPTIONS
Because of the deep integration of cameras, it is possible to change settings like
aperture, shutter speed or zoom (depending on the camera) directly from the remote
control unit of the Intel® Cockpit Controller (CTR) and/or the Cockpit Control
application on the touchscreen tablet while the system is airborne. To ensure complete
integration into the Intel® Falcon™ 8+ UAV, every payload must undergo mechanical
and electrical modifications. Therefore, only payloads approved by Intel are allowed.
Payloads which have not been integrated might affect the compass calibration due to
magnetic emissions by the camera and could have detrimental effects on the flight
performance. If you require assistance with determining which payload to choose for
your application, please contact our support team: support@intel.com.
The 2nd operator monitor fully assem-
bled.
Figure 2.11: 2nd Operator Monitor Package (continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
