Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 141
3.11. LANDING
It is recommended to use a wide-open space as a landing spot (approximately 10 m
radius around the starting position should be free of obstacles).
3.11.1. Landing in GPS-Mode
Landing in GPS-Mode is recommended. The GPS quality indicated on the Status
Display and the touchscreen tablet must show at least 4 bars.
1. Activate the GPS-Mode.
2. Fly the UAV to a position above the desired landing area at a safe height of at least 3
meters.
3. Descend slowly to a height of 1.5 meters and wait until the UAV is stabilized.
4. Keep the right control stick centered, while carefully moving the left control stick
about half way down to descend slowly.
5. Right before touch-down – at 0.2 - 0.3 m – move the left control stick down
gradually until the UAV lands on the ground. While the Intel® Falcon™ 8+ UAV is on
the ground with running motors, always keep the left control stick in the fully
downward position to avoid any unintentional take-off.
6. Keep the left control stick in the fully downwards position and use the right hand to
simultaneously press the START/STOP button on the CTR for at least one second to
stop the motors.
7. Follow the post-flight check (“POST-FLIGHT CHECK” on page 16) to safely switch
off and store away the complete system.
3.11.2. Landing in Height-Mode
1. Activate the Height-Mode.
2. Fly the UAV to a position above the desired landing area at a safe height of at least 3
meters.
3. Descend slowly to a height of 1.5 meters and wait until the UAV is stabilized.
CAUTION: BEFORE LANDING THE INTEL® FALCON™ 8+ UAV, ALWAYS
ADJUST THE CAMERA TO A HORIZONTAL POSITION TO AVOID
DAMAGING THE LENS ON THE GROUND.
CAUTION: LANDING IN HEIGHT-MODE IS FOR SKILLED PILOTS
ONLY.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
