• If flying in an altitude lower than the set standoff distance, OA will still seek to
avoid collisions, but the set standoff distance may not be maintained.
• When flying between structures always make sure that the set standoff distance
can be maintained in all directions.
• OA may not recognize:
• water and other transparent surfaces
• uniformly colored surfaces, like white walls
• surfaces with no clear texture
• small objects like tree branches.
• OA performance may get degraded, e.g.: stopping too early, seeing objects late,
not maintaining the set standoff distance under the following circumstances:
• surfaces with repetitive patterns, like tiling or corrugated iron
• low light conditions
• fog/snow/rain
• flying straight towards low sun, after/before sunrise/sunset
• flying between buildings/structures, where GPS signal may get obstructed.
Figure 2.29: Obstacle Avoidance: directions covered
Each RealSense module covers a
field of view of 91.2 degrees
horizontally and 58.0 degrees
vertically. With one module facing
forward and one 90° sideways to the
left, a total field of view of
approximately 180° is created.
The two different cones of the two
RealSense modules touch each other
in a distance approximately 2600
mm from the camera.
CAUTION: THE UAV CANNOT DETECT ANY OBSTACLES OUTSIDE OF THE
ABOVE-DESCRIBED FIELDS OF VIEW.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
