Table 5.1: Image Positions of Spherical Panorama Set To 19 mm Focal Length
Table 5.2: Image Positions Of Spherical Panorama Set To 30 mm Focal Length
5.3. QUICK SURVEYING ASSISTANT
This function is available as part of the Survey Package. Survey Assist offers a quick and
easy way to do a mapping flight over a rectangular area, directly from the CTR without
any prior planning on a computer. To do so, the Intel® Falcon™ 8+ UAV is placed in one
corner of the area to be mapped, and the key parameters are entered: attached camera
/ lens combination, desired ground sample distance, image overlaps, length of the lines
and number of lines. With this data, the resulting flying altitude and flight path is
calculated and carried out. An assistant guides the user through all required steps.
CAMERA
PITCH
ANGLE
(DEGREES)
UAV YAW ANGLES (DEGREES)
Row 1 -74 0 90 180 270
Row 2 -55 0 51 102 154 205 257 308
Row 3 -37 0 36 72 108 144 180 216 252 288 324
Row 4 -18 0 30 60 90 120 150 180 210 240 270 300 330
Row 5 0 0 30 60 90 120 150 180 210 240 270 300 330
Row 6 18 0 30 60 90 120 150 180 210 240 270 300 330
Row 7 37 0 36 72 108 144 180 216 252 288 324
Row 8 55 0 51 102 154 205 257 308
Row 9 74 0 90 180 270
Total: 78 images
S.A. UAV YAW ANGLES (DEGREES)
Row 1 -83 0 180
Row 2 -69 0 51 102154205257308
Row 3 -55 0 32 65 98 130163196229261294327
Row 4 -41 0 25 51 77 102128154180205231257282308334
Row 5 -27 0 22 45 67 90 112135157180202225247270292315337
Row 6 -13 0 20 40 60 80 100120140160180200220240260280300320340
Row 7 0 0 20 40 60 80 100120140160180200220240260280300320340
Row 8 13 0 20 40 60 80 100120140160180200220240260280300320340
Row 9 27 0 22 45 67 90 112135157180202225247270292315337
Row
10
41 0 25 51 77 102128154180205231257282308334
Row
11
55 0 32 65 98 130163196229261294327
Row
12
69 0 51 102154205257308
Row
13
83 0 180
Total: 154 images

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
