USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 60
2.5.6.3. Camera settings
After switching the camera ON, the default time is set to 00:00, January 1st 2015 UTC.
As soon as a valid GPS signal is available the camera date and time is set directly by the
Intel Falcon 8+ UAV using the information embedded in the GPS data.
Adjustable camera settings can be accessed on the left or right side of the screen of the
touchscreen tablet of the CTR, when activated by tapping on the respective area in the
lower left and right corner.
Figure 2.27: Camera settings by the control menu items on the touchscreen tablet
Tapping, e.g., on the area (1) in the lower left
corner of the touchscreen tablet opens a con-
trol panel for adjustable camera settings.
Depending on lens type and actual camera set-
tings different settings are adjustable as shown
in the example to the left.
The respective setting, in the PITCH example to
the left, can be adjusted by dragging the slider
depicted to the desired value.
1
