USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 215
Table 6.4: Possible warnings
CAUSE VISUAL SIGNAL POSSIBLE FIX
User SD
card can-
not be
accessed.
<- Check Msg appears in
the status line of the Status
Display. Push the related arrow
LEFT button on the CTR until
the Error Message Screen is
shown. No user SD card
will be shown.
Take out the User SD card, make a
backup copy and format it (file sys-
tem: FAT32, allocation unit size: 32
kilobytes). After reinserting the SD
card into the Intel® Falcon™ 8+ UAV, it
should be accessible.
If no backup copy is needed, the User
SD card can also be formatted
directly by the UAV. To do so:
1. Push ENT to open the menu on
the Status Display.
2. Push the arrow RIGHT button to
navigate to Settings.
3. Push ENT and use the arrow
RIGHT button to navigate to
Format User SD.
4. Push ENT to confirm. The shown
screen appears:
5. Push ENT to confirm the
formatting of the User SD card.
The process starts, a progress bar
is shown. Pushing ESC cancels the
function and brings you back to
the Main Screen.
When the formatting of the SD card is
finished, the Intel® Falcon™ 8+ UAV
will immediately create a new log file
and start logging again.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
