USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 81
Product Warranty
Product warranty is limited to original defects in material and workmanship. Warranty
does not cover collateral damage. Due to the nature and use of this product there is no
long-term warranty. Misuse, abuse, incorrect charging, failure to comply with the above
warnings and guidelines, and other inappropriate use of this product are not covered
under warranty.
2.7. TRANSPORT CASES & INTEL® BACKPACK
The transport set consists of different cases with precision water jet cut inlays designed
for the Intel® Falcon™ 8+ UAS with all its accessories. For easy one-person
transportation, the Intel® Falcon™ 8+ UAS cases have retractable handles and wheels.
The Intel® Backpack is not safe for air freighting, but very useful for missions in remote
areas, since it is light and relatively compact.
Figure 2.36: Transport Cases & Backpack
The transport cases offer great advantages:
• Thanks to fold-able handles and wheels,
they can be easily transported by one per-
son.
• The foam bolster inlay of the payload case
can be used as load security for the payload
when the UAV is transported with mounted
payload in the Intel® Falcon™ 8+ UAV case.
If transported by plane - please follow the pre-
scribed guidelines from the air freight carrier.
CAUTION: THE INTEL® FALCON™ 8+ UAV AND THE INTEL® COCKPIT
CONTROLLER (CTR) MUST BE TRANSPORTED FULLY ASSEMBLED.
FOR SECURE TRANSPORTATION WE RECOMMEND USING THE
SUPPLIED CASES.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
