Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 62
Figure 2.28: Firmware update process
1. Install the downloaded Intel Android
USB driver on the same PC you
installed the PFT.
2. Start the Intel PFT Lite application.
3. Open the firmware (.ZIP) file by
selecting Browse... in the upper
right corner.
4. Open the small hatch on the right side
of the payload front side to reveal the
USB-C port of the payload.
5. Connect one end of an USB type C
cable (not supplied) to the port and
the other end to the computer running
Intel PFT.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
