3.6.2. Height-Mode
Attitude and height control is active. When there is no input from the pilot, the UAV will
only:
• Keep its orientation in the air (system will be leveled).
• Keep its height within the limits of the height controller (approximately 1 – 3 m).
For safety reasons and to make operation as easy as possible, there are some
limitations:
• Roll and pitch angles are limited to 50°.
• Ascend rate is limited to 3 m/s.
• Descend rate is limited to 3 m/s.
In this mode the inputs, via the CTR, control the roll and pitch angles of the UAV. For
example, giving full input to the left (using the right control stick, which controls pitch
and roll) means the UAV will roll 50° to the left. With this configuration, the wind
direction and speed will influence the direction and speed of the UAV.
Table 3.3: Controlled parameters in Height-Mode
HGT
BUTTON
GPS
BUTTON
ATTITUDE
CONTROL
HEIGHT
CONTROL
POSITION
CONTROL
Height-Mode ON OFF √√-
CAUTION: THE SYSTEM WILL NEITHER KEEP ITS POSITION NOR
COMPENSATE FOR WIND. THE POSITION MUST BE HELD MANUALLY
BY THE PILOT.
WARNING AVOID FULL CONTROL STICK INPUTS IN HEIGHT-MODE! THE
UAV CAN BE OVERSTRESSED IN CERTAIN SITUATIONS, SUCH
AS FLYING ABRUPT MANEUVERS WITH A LOW BATTERY.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
