Menu Option 3, Charging Cycles
When LED 3 is flashing, menu option 3 can be activated. The LEDs show the current
battery charging cycles, i.e. how often the battery was charged.
The total number of charging cycles of the battery is shown by the LEDs in a binary
system by powers of 2 from right to left multiplied by 10.
Menu Option 4, Overall Capacity
Menu option 4 shows the current possible amount of charge the battery may hold
when fully charged (as a percentage) compared to the factory battery capacity.
Table 2.10: Charging Cycles
THE LEDS SHOW THE TOTAL NUMBER OF CHARGING CYCLES OF THE BATTERY
FROM RIGHT TO LEFT BEGINNING WITH LED 5 (GREEN) = 20, THIS NUMBER
SHOULD BE MULTIPLIED BY 10
STATUS OF LED NO. 1 2 3 4 5
(EXAMPLES)
CHARGING STATE
OFF OFF OFF OFF ON 20 = 1 X 10 ≙ 0 - 10
OFF OFF OFF ON OFF 21 = 2 X 10 ≙ 11 - 20
OFF OFF OFF ON ON 20 + 21 = 3 X 10 ≙ 21 - 30
OFF OFF ON OFF ON 20 + 22 = 5 X 10 ≙ 41 - 50
OFF ON ON ON ON 20 + 21 + 22 + 23 = 15 X 10 ≙ 141 - 150
Table 2.11: Battery Capacity
THE LEDS SHOW THE CURRENT POSSIBLE BATTERY CAPACITY AS PERCENTAGE
COMPARED TO THE FACTORY BATTERY CAPACITY
STATUS OF LED NO. 1 2 3 4 5 REMAINING CAPACITY
ON OFF OFF OFF OFF 51% - 60%
ON ON OFF OFF OFF 61% - 70%
ON ON ON OFF OFF 71% - 80%
ON ON ON ON OFF 81% - 90%
ON ON ON ON ON > 90%
