USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 15
14.Confirm the battery capacity of the UAV is at least 80% (displayed in the
top line of the tablet).
15.The bottom line in the Status Display shows OK.
16.Is the GPS quality greater than or equal to 4 bars? This is mandatory if you
want to fly in GPS-Mode.
17.Confirm the wind speed is within the operational limits: 16 m/s in Height-
Mode or 12 m/s in GPS-Mode.
18.Choose the correct flight mode (usually GPS-Mode or Height-Mode).
19.Switch the motors on (with both hands, only in idle mode).
While the Intel® Falcon™ 8+ UAV is on the ground with running motors,
always keep the left control stick, which controls the height, in the fully
downward position.
20.Are all the motors running correctly?
21.Ready for take-off!
WARNING VIOLATION OF THE SAFETY PRECAUTIONS RESULTS IN THE
LOSS OF WARRANTY!
Table 1.3: Pre Flight Checklist (Continued)

Table of Contents

Other manuals for Intel FALCON 8+

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel FALCON 8+ and is the answer not in the manual?

Intel FALCON 8+ Specifications

General IconGeneral
TypeOctocopter
Easy to useYes
Product colorBlack, Yellow
Maximum speed16 m/s
Frequency band2.4 GHz
Number of rotors8 rotors
Maximum flight time26 min
Maximum weight capacity2.8 kg
Maximum operating distance1000 m
Maximum pitch angular velocity50 °/sec
Operating temperature (T-T)-5 - 40 °C
Transmitter power consumption100 mW
Built-in processor-
Moving control functionsBackward, Forward, Turn left, Turn right, Upward
Weight and Dimensions IconWeight and Dimensions
Depth817 mm
Width768 mm
Height160 mm
Weight1200 g
Rotor diameter203.2 mm
