Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 150
Acoustic: “Battery empty, land now!”
Tactile: Vibration on the CTR
Text on the Status Display: BATTERY EMPTY!
Text on the tablet: Falcon battery empty.
Land now!
Additionally, the voltage display on the Status Dis-
play flashes.
Voltage of the UAV:
~ <= 14.1 V or the UAV
remaining runtime is below 2
minutes. The audio warning is
repeated every 10 seconds
when the remaining flight
time < 1 minute.
You must land immediately.
The battery and/or UAV can
be damaged if the flight is
continued.
Text on the Status Display:
NO BATTERY REDUNDANCY
Text on the tablet: No battery redundancy!
This warning occurs only if
the motors are turned ON.
The total flight time will be
reduced and no battery
redundancy will be available.
If the warning occurred in-
flight with two batteries
inserted, land immediately
and look for the reason. Pos-
sible reasons could be but
are not limited to:
• One battery was not cor-
rectly inserted
• One battery has a defec-
tive cell.
Table 3.7: Warnings depending on critical battery levels of the UAV (continued)
SIGNALS EXPLANATION

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
