Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 173
Pushing ENT
when
Spherical is
highlighted
opens the
screen on the
right.
In this screen,
you can start
the function
and modify the
focus length.
More informa-
tion about the
option
Spherical
of the
Panorama
function can
be found in
“PANORAMA”
on page 184.
By pushing the
RIGHT/LEFT
arrow buttons
you can select
one of the
menu points.
When select-
ing Camera
Options
, the
next screen
depends on
the mounted
payload (cam-
era).
The informa-
tion on how to
control the
specific pay-
load (camera)
with the Sta-
tus Display is
found in the
respective sec-
tion in “PAY-
LOADS -
CAMERA
OPTIONS” on
page 31.
Table 4.1: Status Display Menu Structure (Continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
