USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 58
For directly after the current flight transferred videos the following directory- and file
structure is valid.
The transferred video files are stored in the same directory on the payload SD card as
the image files of the same flight (see above):
000001_201802191200 = directory name with a consecutive mission number
(000001) date (YYYY/MM/DD) and time (hh/mm)
MAH00001.MPG = video file with consecutive number (00001)
MAH00002.MPG = video file number (00002)
Etc.
Figure 2.25: Confirmation of video file transfer
If video files have been recorded during a mis-
sion, they can be transferred from the camera
SD card to the payload SD card for easier
access.
At the end of the flight the pilot is asked if he/
she wants to transfer the video files.
The pilot has to confirm the transfer of the
video files to the payload SD card. After the
confirmation the transfer will occur automati-
cally.
During the transfer a feedback is given on the
touchscreen tablet (see image to the left).
After a successful transfer to the payload SD
card, the video files will be deleted automati-
cally from the original location on the camera
SD card.
If video files are found on the camera SD card,
upon powering ON the UAS the next time, the
option to transfer them to the payload SD card
is again presented.
If you decide to transfer now, the previously
taken video files will be transferred to the direc-
tory generated for the current flight.
