USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 86
To pack the system case into the card-
board box follow the steps like
described:
1. Place one of the corrugated inserts
into the bottom of the box.
2. Place the two cushions over the ends
of the case.
3. Load the case equipped with the
cushions into the box.
4. Place the second corrugated insert
over the top of the cushioned case
and close the box.
Figure 2.38: Packing Instructions for the cardboard box for the UAV system case

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
