USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 90
Perpetual Software Feature Packages
To check which perpetual software feature packages are activated on your system, turn
ON the Intel® Falcon™ 8+ UAV, the touchscreen tablet and the CTR and confirm the Link
Loss Procedure.
1. Push ENT to open the menu on the Status Display.
2. Use the arrow RIGHT button to navigate to Settings.
3. Push ENT to open the Settings menu.
4. Use the arrow RIGHT button to navigate to Falcon Info and confirm by pushing ENT.
The next screen shows the serial number of the UAV, the installed firmware versions,
and the activated perpetual packages.
Annual Software Feature Packages
To check which annual software feature packages are activated on your system, turn
ON the Intel® Falcon™ 8+ UAV, the touchscreen tablet and the CTR and confirm the Link
Loss Procedure.
1. Push ENT to open the menu on the Status Display.
2. Use the arrow RIGHT button to navigate to Settings.
3. Push ENT to open the Settings menu.
4. Use the arrow RIGHT button to navigate to
Payload Info and confirm by
pushing ENT.
The next screen shows the serial number of the payload, the type of the camera used,
and the activated annual software feature packages with the respective expiration date.
Figure 2.39: Show Activated Perpetual License
Perpetual licenses:
In the example, there are two perpetual software feature
packages activated:
•
Survey = Survey package
• Inspec = Inspection package
Figure 2.40: Show activated annual license
Annual licenses:
In the example, there are two annual software feature
packages with the expiration day (Year/Month/Day) acti-
vated:
• Inspec = Inspection package
• Survey = Survey package
Only licenses/packages with an expiration date shown are
valid.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
