USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 94
The User SD card will not be deleted or formatted by the flight system. We recommend
to regularly make backup copies of these storage devices and reformat them
afterwards. Especially when working on complex projects, during which the logs are
needed for geo-referencing, it is helpful to start with clean storage media.
Internal SD
card cannot
be accessed.
<- Check Msg appears
in the status line of the Sta-
tus Display. Push the
related arrow LEFT button
on the CTR until the Error
Message Screen is shown.
No internal SD card
will be shown.
Switch OFF the Intel® Falcon™ 8+
UAV. Wait 10 seconds and switch it
ON again. During boot up, the internal
SD card will be formatted and it
should again be accessible. If this
does not help, contact the Intel sup-
port team to get instructions on how
to proceed.
Note
The Intel® Falcon™ 8+ UAV can fly without any active logging device. It is the
responsibility of the user to make sure that all flights can be properly logged if it
is a legal requirement in the country where the system is used.
Table 2.14: Possible Warning (continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
