Chapter 13: Alarm and event setup
112 TruVision NVR 11 User Manual
Option Description
Set up the intrusion panel connection parameters:
1.
Enable Intrusion Panel
Connection
Select this checkbox to enable the intrusion panel connection.
2. Select Intrusion Panel Select which panel you want to set-up. Up to three panels can
be set up.
3. Name Intrusion Panel Enter a name for the panel.
4. Number Of Zones Up to 32 panel zones can report to the recorder. The number
cannot be increased but you can allocate a different ID for each
zone under the “Intrusion Zone Setup” menu.
5. IP Address Intrusion Panel Enter the panel’s IP address. The IP address must be in the
same LAN as the recorder.
6. Server Port Enter the port that is used to report the events. Default is 9999.
This port number must match the port number set up in the
intrusion panel.
Set up the heartbeat alarm parameters:
7. Enable Panel Heartbeat
Alarm
Select this checkbox to enable the panel heartbeat alarm. The
heartbeat alarm will then be reported to the recorder.
8. Heartbeat Interval (s) Enter the interval between two heartbeats. It is measured in
seconds. Default is 120 s. This interval is valid even if the
“Enable Panel Heartbeat Alarm” checkbox is disabled.
To be able to trigger a heartbeat alarm when the heartbeat is
not received within this interval, enable the “Enable Panel
Heartbeat Alarm” checkbox.
The recorder heartbeat interval must always be higher than that
of the intrusion panel.
9. Actions Click the button to set up the actions linked to the panel
heartbeat alarm. Go to step 3.
Set up the panel arming event parameters:
