Chapter 5: Live view
TruVision NVR 11 User Manual 31
Single and multiview display mode
The recorder has single and multiview formats. The number of multiview display modes
available depends on the recorder model.
Single view display
format
Press the numeric button on the front panel to switch to the corresponding
camera display. For example, press button 4 to view camera 4.
-Or-
Right-click the mouse and select Single Camera from the menu. Select the
required camera from the list.
Multiple view display
format
Press the Display button on the front panel to cycle through different display
formats.
-Or-
Right-click the mouse and select Multi Camera from the menu. Select the
desired multiview display layout.
Sequencing cameras
The sequencing feature allows a camera to be displayed briefly on screen, before
advancing to the next camera in the sequence list. Sequencing can only be done in
single-view display mode.
The default sequence displays each camera in numerical order. However, each camera
on a recorder can have a pre-programmed dwell time and sequence order. See
“Layout” on page 64 for more information.
Note: You must first set up the sequence dwell time under the Display menu. The dwell
time must not be set to zero for sequencing to function.
Sequencing cameras using the front panel:
Select the camera where you want to start sequencing. Press the Seq button on
the front panel to start sequencing. Press it again to stop sequencing.
Sequencing cameras using the mouse:
Select the camera where you want to start sequencing. Right-click the mouse and
select Start Sequence to start the sequencing. Right-click again and select Stop
Sequence to stop sequencing.
Live view toolbar
The live view toolbar in live view lets you quickly access regularly used commands.
Position the cursor over a video image and left- click the mouse. The toolbar appears
(see Figure 11 on page 32).
