Event V3 Manual 17
© Jands Electronics July 1995
4.30 Connecting Desklights
Desklights are available as an optional accessory. Only 12V Littlite or compatible
desklights with 3-pin Cannon XLR type connectors should be used (for wiring see
Appendix B).
4.40 Connecting a VDU
Connect from any Monochrome, CGA, EGA or VGA monitor to the connector on
the option panel. Two video output options are available to suit the above range of
monitors (for wiring see Appendix B).
4.50 Connecting a MIDI Device
The Event console is equipped with a MIDI input (there is no through connector).
Use a standard MIDI cable to conect from the MIDI device to the MIDI In connector
on the backpanel (for wiring see Appendix B).
4.60 Connecting a Slave Console
Any Jands Stage 12, ESP II or Event console can be slaved to the Event.
Connect from the DMX output of the slave console to the MIDI input of the main
console. This cable should be wired as detailed (for wiring see Appendix B).
4.70 Turning the Power On
Once all connections have been made the console can be turned on using the mains
power switch located next to the power lead input.
