14.00 Overall Master Controls

14.10 P1 and P2 Faders

The P1 Master fader scales the top row of Preset faders, likewise the P2 Master fader

scales the overall level of the bottom row of Preset faders. By moving the P1 fader

up while moving the P2 fader down it is possible to crossfade between the settings

on the two rows of channel Preset faders.
