Section 20 Failures and After-Sale Services 20-4
Repair Circuit Block (JAN-7201)
Location Circuit Block Name Model Name Remarks
Display unit
Display unit NWZ-207
Display unit
FAN kit for changing the 19inch
MNU
7ZYNA4004 For NWZ-207
Display unit
Display unit
NWZ-214
Display unit
FAN kit for changing the 19inch
MNU
7BFRD0008 For NWZ-214
Trackball operation unit Trackball unit
CCK-1060
Trackball operation unit Operation circuit A
CCK-1050
Trackball operation unit Operation circuit SW
CCK-1069
Trackball operation unit Operation circuit CN
CCK-1070
Trackball operation unit
Interior of the trackball operation
unit
CMD-1103
Keyboard operation unit Operation circuit B
CCK-1059
Keyboard operation unit Keyboard unit
CCK-1061
Keyboard operation unit
Interior of the keyboard operation
unit
CMD-1106
Power supply unit Power supply unit
NBD-913
Power supply unit PSU replacement FAN kit
7ZYNA4007
Central control unit CCU repair kit
NZC-1590/A
Central control unit SSD 256GB
CDD-753
Central control unit DVD drive
CDD-754
Central control unit
FAN kit for changing the CCU
7ZYNA4006
Central control unit
Lower screw cover
MTV305169
Central control unit
Upper screw cover
MTV305170
Central control unit
Serial LAN interface circuit
CMH-2370
Central control unit
Gyro interface circuit
CMJ-554
Central control unit
Rader interface circuit
CQD-2273
Central control unit
Analog option circuit
CMJ-560
