19-41 Section 19 Maintenance & Inspection
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
21
23
24
24
26
27
19.7 Firmware Update
Explain firmware update of this product.
Note
When the firmware update is started, the active task is automatically terminated.
Please complete necessary operations, such as saving settings, before updating starts.
1 Click on the [Menu] button on the left Tool Bar.
The menu is displayed.
2 Change over to the second page using the page switching button, and click
[Maintenance] - [Software Update].
The [Software Update] dialog box appears.
3 Click on the [Software Update] button.
