JRC ECDIS User Manual

B-79 Appendix B Menu List and Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
APP B
24
25
27
APP C
Object name
Icon button
display example
Remarks
Retro-reflector
Sand waves
Sea area/named water area
Seabed area
Sea-plane landing area
Shoreline construction
Signal station, traffic
Signal station, warning
Silo/tank
Slope topline
Sloping ground
Small craft facility
Sounding
Spring
Tidal stream - flood/ebb
Tidal stream - harmonic prediction
Tidal stream - non-harmonic prediction
Tidal stream - time series
Tidal stream panel data
Tide - harmonic prediction
Tide - non-harmonic prediction
Tide - time series
Topmark
Underwater/awash rock
Vegetation
Water turbulence
Weed/Kelp
Wreck

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
