Appendix B Menu List and Materials B-98
Object name
Icon button
display example
Remarks
Sand waves
Sea area/named water area
Object name attribute value
is "Text"
Seabed area
Nature of surface attribute
value is "mud"
Sea-plane landing area
Shoreline construction
Silo/tank
Sloping ground
