Section 22 Specifications 22-14
22.13 Sensor LAN switch unit
GENERAL SPECIFICATION NQA-2443: Sensor LAN switch unit
Technology
Standards IEEE802.3, 802.3u, 802.3x
Processing type
Store and Forward, with IEEE802.3 full duplex,
back pressure flow control
Forward and Filtering Rate 148810 pps
Latency Less than 5us
Interface
Number of ports 16
RJ45
10/100BASE-T(X) auto negotiation speed, F/H duplex mode, and
auto MDI/MDI-X connection
LED Power, Fault, Speed
Power
Input Voltage 12 to 48 VDC
Input Current 0.34A max
Over Current Protection 1.6A
Reverse Polarity Protection Yes
Mechanical
Dimension Width 75.0 x Depth 105 x Height 179 (mm)
Mass 1.5kg
Environment
Operational Temperature -15C to +55C
Operational Humidity 40C RH 93%
Vibration
Sweep 2 Hz to 13.2 Hz at ± 1 mm, 13.2 Hz to 100 Hz at 7m/s
2
and for 2h on each resonance, otherwise 2h at 30 Hz in all three
axes
EMC IEC60945-Ed4.0
