Section 19 Maintenance & Inspection
19.1 Maintenance Functions Executed
from Menu
This section explains maintenance functions that are executed from the menu.
19.1.1 Starting maintenance functions
1 Click on the [Menu] button on the left Tool Bar.
The menu is displayed.
2 Click on the [Maintenance] button on the menu.
The submenu is displayed.
3 Click on a button on the submenu.
The dialog box of the selected maintenance function is displayed.
19.1.2 Setting Date/Time/Time Zone
1 Click on the [Menu] button on the left Tool Bar.
The menu is displayed.
2 Click on the [Maintenance] - [Date/Time/Time Zone] button on the menu.
The [Date/Time/Time Zone] dialog box appears.
[3]
[2]
[1]
[5]
[6]
[4]
[7]
