JRC ECDIS User Manual

Section 22 Specifications 22-12
22.10 Keyboard OPU
GENERAL SPECIFICATION NCE-5625: Keyboard Operation Unit
PC Keyboard
Layout QWERTY
Pitch 15mm
Stroke 2mm
Dedicated Keys
Keys
HOME, TX/STBY, PI, DISP OFF, AZ, PANEL, DAY/NIGHT,
MOB, USER1, USER2
Knobs EBL, VRM, SEA, RAIN, GAIN
Mechanical
Dimension Width 270 x Depth 210 x Height 30 (mm)
Mass 0.8kg
Environment
Operational Temperature -15C to +55C
Operational Humidity 40C RH 93%
Vibration
Sweep 2 Hz to 13.2 Hz at ± 1 mm, 13.2 Hz to 100 Hz at
7m/s2 and for 2h on each resonance, otherwise 2h at 30
Hz in all three axes
EMC IEC60945-Ed4.0
Ingress Protection Rating Front : IP22
22.11 26inch Display Unit Mount Kit
GENERAL SPECIFICATION CWA-246: 26inch Display Unit Mount Kit
Mechanical
Dimension Width 680 x Depth 718 x Height 1100 (mm)
Mass APPROX. 65kg
Environment
Operational Temperature -15C to +55C
Operational Humidity 40C RH 93%
Vibration
Sweep 2 Hz to 13.2 Hz at ± 1 mm, 13.2 Hz to 100 Hz at
7m/s
2
and for 2h on each resonance, otherwise 2h at 30Hz
in all three axes
EMC IEC60945-Ed4.0
Ingress Protection Rating Front : IP22

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
