JRC ECDIS User Manual

19-47 Section 19 Maintenance & Inspection
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
21
23
24
24
26
27
19.9 Confirming Maintenance INFO
19.9.1 Screen items/fields and their function
Maintenance INFO can be confirmed.
1 Click on the [Menu] button on the left Tool Bar.
The menu is displayed.
2 Click on the [Maintenance] - [Maintenance INFO] button on the menu.
The screen can be switched to either the standard window or the expanded window.
An example of an expanded window is shown above.
For the screen switching method, refer to "19.9.2 Switching to the standard window or the expanded
window."
(1) (2)
(3)
(4)
(5)

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
