19-13 Section 19 Maintenance & Inspection
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
21
23
24
24
26
27
19.1.5 Displaying and Resetting the Current Voyage
Distance
This equipment displays the current voyage distance (estimated voyage distance) that is calculated
from the speed over the ground and the speed through the water.
The voyage distance can also be reset.
Note
While the ship is anchored or sailing at low speed, it takes up to around 2 minutes to reset the
current voyage distance.
1 Click on the [Menu] button on the Left Tool Bar.
A menu is displayed.
2 Click on [Maintenance] - [Voyage Distance] on the menu.
The [Voyage Distance] dialog is displayed.
[1] [X] button
The [Voyage Distance] dialog is closed.
[2] [Current Voyage Distance]
The current voyage distance is displayed.
[Ground]: Indicates the current voyage distance that is calculated from the speed over the ground.
[Water]: Indicates the current sea distance that is calculated from the speed through the water.
[1]
[2]
[3]
