JRC ECDIS User Manual

Section 19 Maintenance & Inspection 19-34
19.6 Software Update
This section describes software update of this equipment.
Note
When software update starts, the tasks that are active are automatically terminated. Complete the
necessary operation such as saving of settings prior to the start of update.
19.6.1 Local Update
1 Set the CD/DVD or USB flash memory containing the update data.
2 Click on the [Menu] button on the left Tool Bar.
The menu is displayed.
3 Change over to the second page using the page switching button, and click
[Maintenance] - [Software Update].
The [Software Update] dialog box appears.
4 Click on the [Software Update] button.

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
