JRC ECDIS User Manual

B-115 Appendix B Menu List and Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
APP B
24
25
27
APP C
Specifies the defining characteristics of a ‘new object’.
Remarks:
Identical definitions must be used for other instances of identical features being encoded.
The wording for the attribute CLSDEF must be approved by TSMAD before use.
Attribute: Object class name
Acronym: CLSNAM Code: 191
Attribute type: S
Definition:
Specifies the descriptive name of a ‘new object’ feature object class.
Remarks:
All ‘new objects’ of the same class must share the same CLSNAM.
The wording for the attribute CLSNAM must be approved by TSMAD before use.
Attribute: Object name in national language
Acronym: NOBJNM Code: 301
Attribute type: S
References:
INT 1: ID 7, IF 19, IN 12.2-3;
M-4: 371; 323.1-2; 431.2-3; 431.5;
Indication:
Name of object (c...):string of national language characters
Format:
c...
Remarks:
The attribute 'object name in national language' encodes the individual name of an object in the
specified national language.
Attribute: Pilot district in national language
Acronym: NPLDST Code: 302
Attribute type: S
References:
INT 1: IT 1.2;
M-4: 491.1-2;
