Appendix B Menu List and Materials B-100
Object name
Icon button
display example
Remarks
Tidal stream - time series
Tidal stream panel data
Tide - harmonic prediction
Tide - non-harmonic prediction
Tide - time series
Tideway
Object name attribute value
is "Text"
Traffic separation scheme crossing
