JRC ECDIS User Manual

Section 17 Adjusting and Setting up Equipment (for Services) 17-2
2 Change over to the second page using the page switching button, and click the [Code
Input] button.
The password input dialog is displayed.
3 Enter 0 in Password.
4 Click on the [MENU] button on the left toolbar.
The menu is displayed.
5 Change to the 2nd page by using the page change button.
The [Service] button is added.
6 Click on the [Service] button.
The submenu is displayed.
7 Display a submenu dialog box by clicking on one of the [Adjustment], [Installation],
and [Maintenance] buttons.

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
