JRC ECDIS User Manual

Section 22 Specifications 22-2
22.2 JAN-7201
GENERAL SPECIFICATION JAN-7201
Display 19inch LCD
Bearing Indication Relative motion mode: North UP/Course UP/Head
UP/Waypoint UP
True motion mode: North UP/Course UP
Operation Cursor and keys
External media General purpose USB port  1 and DVD drive
Ambient Condition
- Operating Temperature
Scanner Unit: -25C to +55C (Storage: -25C to +70C)
Other Unit: -15C to +55C
Ambient Condition
- Relative Humidity
+40C, 93%
Ambient Condition
- Vibration
2 to 13.2Hz: Amplitude 1mm 10%
13.2 to 100Hz: Acceleration 7m/s
2
Power Supply Input 100 to 115VAC, 50/60Hz 1
220 to 240VAC, 50/60Hz 1
24VDC
Power Consumption Rating: Approx. 220VA
(DC:72W at AC power outage)
Power Supply Voltage Fluctuation AC input: 10%
DC input: +30%, -10%
Processing Unit
Central Control Unit NDC-1590/A
Power Supply Unit NBD-913
Trackball Operation Unit NCE-5605
Display
Display NWZ-207/NWZ-214
Option Unit
Keyboard Operation Unit NCE-5625
Operation Unit Desktop Frame Rack CWB-1596
Large tray CWB-1593
Junction Box NQE-1143
Sensor LAN Switch Unit NQA-2443/A
19inch Desktop Frame Rack CWB-1594/CWB-1659
19inch Display Unit Mount Kit CWA-245
Buzzer unit CGC-25
Safe Distance For Standard Compass
Display unit 2.4m

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
