B.1.17 Service
Adjustment ECDIS
Basic Adjustment
Tune Adjustment
*
* Under magnetron radar connection
Bearing Adjustment
Range Adjustment
Master/Slave (radar operation mode)
TXRX
Antenna Height
Tune Peak Adjustment
*
* Under magnetron radar connection
Tune Indicator
Output BP
Input BP Count (Menu for a person in charge of installation)
RADAR1
RADAR2
Output BP Count (Menu for a person in charge of installation)
Output BP
Echo Noise Level (Menu for a person in charge of installation)
Echo Noise Level
Adjustment Mode
MBS
Initial Level
Area Offset
Cable Attenuation (Menu for a person in charge of installation)
Correction Level
ECDIS CONNING

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
