JRC ECDIS User Manual

B-81 Appendix B Menu List and Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
APP B
24
25
27
APP C
Object name
Icon button
display example
Remarks
Alert line
Arrow(Start To End/Small)
Arrow(Start To End/Medium)
Arrow(Start To End/Large)
Arrow(End To Start/Small)
Arrow(End To Start/Medium)
Arrow(End To Start/Large)
Arrow(Both Direct/Small)
Arrow(Both Direct/Medium)
Arrow(Both Direct/Large)
Archipelagic Sea Lane Axis
Berth
Bridge
Object name attribute
value is "Text"
Cable, overhead
Text

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
