Appendix B Menu List and Materials B-84
Object name
Icon button
display example
Remarks
Railway
Rapids
Recommended route centerline
Orientation attribute value
is "Text"
Recommended track
Orientation attribute value
is "Text"
River
Road
Runway
Sand waves
Seabed area
Nature of surface attribute
value is "mud"
Shoreline construction
Slope topline
Straight territorial sea baseline
Tideway
Traffic separation line
Traffic separation scheme boundary
Text
