Appendix B Menu List and Materials B-88
Object name
Icon button
display example
Remarks
Administration Area (Named)
Airport/airfield
Anchor berth
Anchorage area
Object name attribute value
is "Text"
Archipelagic Sea Lane
Berth
Object name attribute value
is "Text"
Bridge
Object name attribute value
is "Text"
Text
