Category
name
Object name
Icon button display
example
Alert generated when the
own ship approaches the
object
(Routes) Regulated two-way
recommended route
centerline, based on fixed
marks
No alert
Regulated one-way
recommended route
centerline, based on fixed
marks
No alert
Non-regulated
recommended two-way
track, based on fixed marks
Dangerous line
Non-regulated
recommended one-way
track, based on fixed marks
Dangerous line
Archipelagic Sea Lane No alert
(Restricted
Area)
Boundary of an area where
entry is prohibited or
restricted
Dangerous line
Boundary of a restricted
area
Dangerous line
(Administrat
ed Area)
Jurisdiction boundary No alert
(Fishing
Ground)
Boundary of an area where
trawling or fishing is
prohibited or restricted
Dangerous line
(Cable/
Pipe)
Boundary of a submarine
cable area
Dangerous line
Submarine cable No alert
Oil, gas pipeline,
submerged or on land
No alert
Water pipeline, sewer, etc. No alert
(Miscella-
neous
Boundary)
Boundary between IALA-A
and IALA-B systems of
lateral buoys and beacons
No alert
